Submersible Pumps
EL Series (EL110-EL200)
Products
Technical specifications
EL Series (EL110-EL200)
Here to help on those massive projects, Dragflow’s biggest electrical pumps are designed for dredging or mining applications where production is the main driver. Moreover, they’re fully customizable to fit your projects needs.
This series is available in version with oversized motor (S).
Main features
- Pump provided of agitator to stir things up
- High abrasion resistance
- Low rotation speed
- Able to handle up to 70% per weight material density
Accessories
- Deep immersion system
- Cutting blade
- Humidity and temperature sensor
- Jet Ring system
Type
Submersible Pumps
Brand
Dragflow
Power
107-201 hp
Discharge
8 in
RPM
894-1176
Maximum Capacity
1541 gpm
Maximum Head
98-157 ft
| Model | Discharge | Capacity | Head | Power | RPM | Solid Handling | Weight | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | m3/h | USgpm | m | ft | HP | kW | 50 Hz | 60 Hz | mm | in | kg | lb | |
| EL110 | 200 | 8 | 350 | 1541 | 30 | 98 | 107 | 80 | 745 | 894 | 60 | 2,4 | 2450 | 5400 |
| EL110S | 200 | 8 | 350 | 1541 | 30 | 98 | 150 | 110 | 745 | 894 | 60 | 2,4 | 2450 | 5400 |
| EL180 | 200 | 8 | 350 | 1541 | 40 | 131 | 180 | 130 | 980 | 1176 | 60 | 2,4 | 2750 | 6060 |
| EL180S | 200 | 8 | 350 | 1541 | 40 | 131 | 201 | 150 | 980 | 1176 | 60 | 2,4 | 2900 | 6400 |
| EL200 | 200 | 8 | 350 | 1541 | 48 | 157 | 201 | 150 | 980 | 1176 | 60 | 2,4 | 3000 | 6600 |
