Submersible Pumps
EL Series (EL25-EL35)
Products
Technical specifications
EL Series (EL25-EL35)
Versatile and mobile, the Dragflow mid-range electric pumps cover a huge variety of heads and flows with many accessories that can adapt them to any application.
This series is available in version with oversized motor (S) and high capacity (HC).
Main features
- Pump provided of agitator to stir things up
- High abrasion resistance
- Low rotation speed
- Able to handle up to 70% per weight material density
Accessories
- Deep immersion system
- Cutting blade
- Humidity and temperature sensor
- Jet Ring system
Type
Submersible Pumps
Brand
Dragflow
Power
25-35 hp
Discharge
4 in
RPM
1164
Maximum Capacity
396-925 gpm
Maximum Head
49-102 ft
| Model | Discharge | Capacity | Head | Power | RPM | Solid Handling | Weight | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | m3/h | USgpm | m | ft | HP | kW | 50 Hz | 60 Hz | mm | in | kg | lb | |
| EL25 | 100 | 4 | 100 | 440 | 21 | 69 | 25 | 18,5 | 970 | 1164 | 35 | 1,4 | 715 | 1580 |
| EL25S | 100 | 4 | 100 | 440 | 21 | 69 | 35 | 26 | 970 | 1164 | 35 | 1,4 | 785 | 1730 |
| EL35 | 100 | 4 | 90 | 396 | 31 | 102 | 35 | 26 | 970 | 1164 | 35 | 1,4 | 780 | 1580 |
| EL35S | 100 | 4 | 90 | 396 | 31 | 102 | 60 | 45 | 970 | 1164 | 35 | 1,4 | 780 | 1580 |
| EL35HC | 100 | 4 | 210 | 925 | 15 | 49 | 35 | 26 | 970 | 1164 | 60 | 2,4 | 780 | 1580 |
