Engine Driven Pumps
EPT Series
Products
Technical specifications
EPT Series
The Tsurumi EPT Series engine-driven trash pumps feature an oversized pump casing and a removable cleanout door that eliminates the need to take off the suction hose for access.
EPT3 Models
The EPT3 models, featuring 2″, 3″, and 4″ trash pumps (EPT3-50HA, EPT3-80HA, and EPT3-100HA, respectively), are each equipped with a heavy-duty Honda GX series gas engine and a low oil sensor.
- Silicon Carbide mechanical seal ensures the longest life in its class.
- High Chrome impeller, Cast Iron volute casing, and Stainless Steel wear plate for increased durability and reduced maintenance.
- Pump/engine set is mounted to a cage frame on Rubber Vibration Cushions to absorb stress and wear.
- Durable Rolled-Steel frame provides maximum protection, easy handling or transport, and safe operation.
- EPT-50HA Model features a Honda GX160 gas engine with a low oil sensor.
- EPT-80HA Model features a Honda GX240 gas engine with a low oil sensor.
- EPT-100HA Model features a Honda GX340 gas engine with a low oil sensor.
EPT5 Models
The EPT5 models, featuring an industrial 6″ trash pump (EPT5-150HA and EPT5-150KD, respectively), are powered by Honda gas engine and Koehler diesel engine.
- Cast Aluminum casing and adapter
- Cast iron wear plate, volute, and manifold
- Stainless steel impeller
- Silicon carbide mechanical seal, Buna o-rings, and flapper/check valve
- 6″ NPT port size
- Self-priming up to 20ft.
- EPT5-150HA comes with a Honda GX670 Gas Engine
- EPT5-150KD comes with a Koehler KDW1003 Diesel Engine
- Solids handling up to 3″ diameter
- Unique slide mechanism allows complete pump service without hose or component removal from the trailer (Patented)
- Includes a seal wash feature for extended seal life
- 12 VDC electric start; digital tachometer/hourmeter included
- D.O.T. approved trailer – refer to state and local codes for registration
Type
Engine Driven Pumps
Brand
Tsurumi
Power
5.5-24 hp
Discharge
2-6 in
RPM
3600-4000
Maximum Capacity
990 gpm
Maximum Pressure
95 ft
| Model | Discharge Size (in) | Motor Output (hp) | Diameter (in) | Height (in) | Max Solid Diameter (in) | Weight (lbs) |
|---|---|---|---|---|---|---|
| EPT3-50HA | 2 | 5.5 | 18 1/4 | 17 3/8 | 0.787 | 82 |
| EPT3-50V | 2 | 5 | 17 1/8 | 17 5/8 | 0.787 | 88 |
| EPT3-80HA | 3 | 8 | 20 1/8 | 17 3/8 | 1.22 | 160 |
| EPT3-100HA | 4 | 11.0 | 20 1/8 | 26 | 1.22 | 160 |
| EPT3-100V | 4 | 11.0 | 20 1/4 | 22 3/8 | 1.22 | 157 |
| EPT5-150HA | 6 | 22 | 48 | 60 | 3 | 1125 |
| EPT5-150KD | 6 | 23.4 | 48 | 60 | 3 | 1250 |
