Submersible Pumps
SQ Series
Products
Technical specifications
SQ Series
Grundfos SQ Series pumps merge cutting-edge design with robust construction, offering the versatility of standard 4-inch pumps in a compact 3-inch diameter.
Their lightweight build facilitates swift and straightforward installation, particularly in challenging well conditions. Setting a new benchmark for submersible pumps, Grundfos SQ pumps boast a range of advanced features. Through the integration of advanced electronics with permanent-magnet motors, we achieve unprecedented control and communication capabilities with the pumps. Notable features resulting from this integration include Soft-Start and integrated Dry-Run Protection.
Features
- Dry-running protection
- High-efficiency permanent magnet motor
- Enhanced durability with floating impellers
- Upthrust prevention
- High flow velocity
- Motor wear reduction through Soft-start
- Protection against over- and under-voltage, overload, and high temperatures
Type
Submersible Pumps
Brand
Grundfos
Power
1/2-1.5 hp
RPM
40 gpm
Maximum Capacity
778 ft
Maximum Pressure
3000-10700
| Model | Power (hp) | Motor size (in) | Discharge Size (in) | Height (in) | Diameter (in) | Weight (lbs) |
|---|---|---|---|---|---|---|
| 5SQ/SQE05-90 | 1/2 | 3″ | 1″ NPT | 30.4 | 2.9 | 12 |
| 5SQ/SQE05-140 | 1/2 | 3″ | 1″ NPT | 30.4 | 2.9 | 12 |
| 5SQ/SQE05-180 | 1/2 | 3″ | 1″ NPT | 31.5 | 2.9 | 12 |
| 5SQ/SQE07-230 | 3/4 | 3″ | 1″ NPT | 33.6 | 2.9 | 13 |
| 5SQ/SQE07-270 | 3/4 | 3″ | 1″ NPT | 33.6 | 2.9 | 13 |
| 5SQ/SQE07-320 | 3/4 | 3″ | 1″ NPT | 34.6 | 2.9 | 13 |
| 5SQ/SQE10-360 | 1 | 3″ | 1″ NPT | 38.2 | 2.9 | 16 |
| 5SQ/SQE10-410 | 1 | 3″ | 1″ NPT | 38.2 | 2.9 | 16 |
| 5SQ/SQE15-450 | 1 1/2 | 3″ | 1″ NPT | 39.3 | 2.9 | 16 |
| 10SQ/SQE05-110 | 1/2 | 3″ | 1 1/4″ NPT | 30.4 | 2.9 | 12 |
| 10SQ/SQE05-160 | 1/2 | 3″ | 1 1/4″ NPT | 30.4 | 2.9 | 12 |
| 10SQ/SQE07-200 | 3/4 | 3″ | 1 1/4″ NPT | 31.5 | 2.9 | 13 |
| 10SQ/SQE07-260 | 3/4 | 3″ | 1 1/4″ NPT | 33.6 | 2.9 | 13 |
| 10SQ/SQE10-290 | 1 | 3″ | 1 1/4″ NPT | 35.0 | 2.9 | 16 |
| 10SQ/SQE15-330 | 1 1/2 | 3″ | 1 1/4″ NPT | 36.14 | 2.9 | 16 |
| 15SQ/SQE05-70 | 1/2 | 3″ | 1 1/4″ NPT | 30.4 | 2.9 | 12 |
| 15SQ/SQE05-110 | 1/2 | 3″ | 1 1/4″ NPT | 30.4 | 2.9 | 12 |
| 15SQ/SQE07-150 | 3/4 | 3″ | 1 1/4″ NPT | 31.5 | 2.9 | 13 |
| 15SQ/SQE07-180 | 3/4 | 3″ | 1 1/4″ NPT | 33.6 | 2.9 | 13 |
| 15SQ/SQE10-220 | 1 | 3″ | 1 1/4″ NPT | 35.0 | 2.9 | 16 |
| 15SQ/SQE10-250 | 1 | 3″ | 1 1/4″ NPT | 36.1 | 2.9 | 16 |
| 15SQ/SQE10-290 | 1 1/2 | 3″ | 1 1/4″ NPT | 38.2 | 2.9 | 16 |
| 22SQ/SQE05-40 | 1/2 | 3″ | 1 1/2″ NPT | 30.4 | 2.9 | 12 |
| 22SQ/SQE05-80 | 1/2 | 3″ | 1 1/2″ NPT | 30.4 | 2.9 | 12 |
| 22SQ/SQE07-120 | 3/4 | 3″ | 1 1/2″ NPT | 31.5 | 2.9 | 13 |
| 22SQ/SQE10-160 | 1 | 3″ | 1 1/2″ NPT | 33.6 | 2.9 | 13 |
| 22SQ/SQE10-190 | 1 | 3″ | 1 1/2″ NPT | 38.2 | 2.9 | 16 |
| 22SQ/SQE15-220 | 1 1/2 | 3″ | 1 1/2″ NPT | 38.2 | 2.9 | 16 |
| 30SQ/SQE05-40 | 1/2 | 3″ | 1 1/2″ NPT | 30.4 | 2.9 | 12 |
| 30SQ/SQE07-90 | 3/4 | 3″ | 1 1/2″ NPT | 30.4 | 2.9 | 13 |
| 30SQ/SQE10-130 | 1 | 3″ | 1 1/2″ NPT | 35.0 | 2.9 | 13 |
| 10SQE-05-100NE | 1/2 | 3″ | 1 1/4″ NPT | 30.4 | 2.9 | 12 |
| 10SQE-05-140NE | 1/2 | 3″ | 1 1/4″ NPT | 30.4 | 2.9 | 12 |
| 10SQE-05-180NE | 3/4 | 3″ | 1 1/4″ NPT | 31.5 | 2.9 | 13 |
| 10SQE-07-220NE | 3/4 | 3″ | 1 1/4″ NPT | 33.6 | 2.9 | 13 |
| 10SQE-10-260NE | 1 | 3″ | 1 1/4″ NPT | 35.0 | 2.9 | 16 |
| 10SQE-10-300NE | 1 | 3″ | 1 1/4″ NPT | 36.1 | 2.9 | 16 |
| 10SQE-10-340NE | 1 | 3″ | 1 1/4″ NPT | 38.2 | 2.9 | 16 |
| 22SQE05-40NE | 1/2 | 3″ | 1 1/2″ NPT | 30.4 | 2.9 | 12 |
| 22SQE05-80NE | 1/2 | 3″ | 1 1/2″ NPT | 30.4 | 2.9 | 12 |
| 22SQE07-110NE | 3/4 | 3″ | 1 1/2″ NPT | 31.5 | 2.9 | 13 |
| 22SQE07-140NE | 3/4 | 3″ | 1 1/2″ NPT | 33.6 | 2.9 | 13 |
| 22SQE10-180NE | 1 | 3″ | 1 1/2″ NPT | 38.2 | 2.9 | 16 |
| 22SQE10-210NE | 1 | 3″ | 1 1/2″ NPT | 38.2 | 2.9 | 16 |
