HY Series (HY18-HY24)
Dragflow small hydraulic pump range can be used on the arm of an excavator and their small dimensions guarantee maximum versatility of use.
Main features
- Pump provided of agitator to stir things up
- High abrasion resistance
- Low rotation speed
- Able to handle up to 70% per weight material density
- Possibility of installation on mechanical arm
- Dredging systems available on request
Accessories
- Deep immersion system
- Cutting blade
- Humidity and temperature sensor
- Jet Ring system
Type
Submersible Pumps
Brand
Dragflow
Power
17-32.5 hp
Discharge
3-4 in
RPM
2000
Maximum Capacity
220-352 gpm
Maximum Pressure
57-121 ft
| Model | Discharge | Capacity | Head | Power | RPM | Solid Handling | Weight | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | m3/h | USgpm | m | ft | HP | kW | 50/60 Hz | mm | in | kg | lb | |
| HY18 | 80 | 3 | 50 | 220 | 17,5 | 57 | 17 | 13 | 2000 | 20 | 0,8 | 170 | 375 |
| HY24 | 100 | 4 | 80 | 352 | 37 | 121 | 32,5 | 24 | 2000 | 25 | 1 | 220 | 485 |
